A power booster, also known as a brake booster, is a device that helps amplify the force applied to the brake pedal in a car. It is a crucial component of the braking system, especially in vehicles with power brakes.
How Does it Work?
When you press the brake pedal, the power booster uses vacuum pressure from the engine to multiply the force, making it easier to engage the brakes. This results in a more responsive and efficient braking system, ensuring a safer driving experience.
Why is it Important?
Having a properly functioning power booster is essential for the overall performance and safety of your vehicle. It ensures that you can stop quickly and effectively, especially in emergency situations, reducing the risk of accidents on the road.
Signs of a Faulty Power Booster
If you notice any of the following signs, it may indicate a problem with your power booster:
- Hard brake pedal
- Brakes feel less responsive
- Hissing sound when pressing the brake pedal
If you experience any of these issues, it is important to have your power booster inspected and repaired by a professional mechanic.
Is a power booster required with disc brakes? Do you have to fit one?
In the past, a booster was an electable option on many mainstream car builds. They're still optional, but they make driving much more comfortable.
I have power drum brakes. Can I use the same booster if I change to disc brakes?
Yes, just be sure to use a correct disc brake master-cylinder. Make sure the piston depth in the back of the master matches the booster outbound piston.
How will I know if my power booster is no longer working?
One way the booster will give a very hard pedal and feel like the vehicle will not stop, it might also make a hissing sound.
How do I check if my power booster is operating properly?
- Turn off the engine.
- Depress the brake pedal a few times to evacuate the booster.
- Apply steady pressure to the pedal and start the engine.
- The pedal should fall slightly.
NOTE: The same problem will happen if the vacuum is too low.
How much vacuum is needed to operate a booster properly?
For a power booster to function properly, you will need at least 18" of vacuum.
Anything lower will give you a hard pedal. Ie; cars with BIG CAMS.
I have a radical cam, is there any way to supplement my low engine vacuum?
Yes, seek help about adding an electric vacuum pump that works off the 12-volt system and gives 21" vacuum. A canister has been known to help as well.
Is there any way to decrease booster size and still maintain assist, especially in cars with tall valve covers or BB, etc?
Yes. By using a dual diaphragm design booster you can maintain a high level of assist while keeping a small size, like an 8" dual-diaphragm booster that fits most street rod and GM applications.
When I step on the brakes, the pedal feels good, but I get no braking. What could cause this?
One reason is a mismatch between the booster pin length and the depth of the master cylinder piston hole. Be sure the hole is not too deep for the booster pin.
I have installed power brakes on my original manual brake car, and now the brakes are extremely sensitive. Why?
There are two attachment points on the brake pedal.For power brakes, you need to use the lower attachment hole. Using the upper hole will make the brakes too sensitive.
Why do my power boosters keep going bad on my vehicles?
You are probably getting corrosive vapors back into the booster. Install a vapor trap, and that should eliminate the problem. Consider the fuel you're using too. Especially with low-grade biofuel, which is really corrosive on most seals.
